Injection Blow Molding – MSZ60H

Belong to Injection Blow Molding

Product Introduction: Horizontal injection, plasticizing stable, easy to operate Single beam structure, easy to remove the mould. Oil system double proportion, the control precision, save energy consumption by more than 25%.

Fill out my online form.

Details

The mold cavity number:

Approx. Volume
(ml)
Max. body diameter
(mm)
Mini. neck diameter
(mm)
Max. Height
(mm)
Min. Weight
(g)
Ceter Distance
(mm)
Max. Cavitation
(cav)
10 22 8 60 3 35 14
30 30 8 75 4 40 18
75 40 13 100 9 65 9
120 50 18 120 15 80 8
250 65 22 140 25 100 6

The equipment size

Technical features:

Horizontal injection, plasticizing stable, easy to operate
Single beam structure, easy to remove the mould.
Oil system double proportion, the control precision, save energy consumption by more than 25%.
Large capacity mold installation size, higher yield
Optional:

Servo drive, and can realize energy-saving 25-45%

The main technical parameters:

Injection System Unit MSZ60H
Screw Diameter mm 50
Screw L/D 20.6~23:1
Injection weight(HDPE) g 280
Max. screw speed rpm 10-235
Heating Capacity kw 10.8
Clamping & blowing system
Clamping force of injection kn 572
Clamping force of blowing kn 89
Max. platen size (LxW) mm 740×390
Min. Mold thickness (H) mm 280
Heating Capacity of mould kw 6
Stripping System
Stripping Stroke mm 200
Dry cycle sec 4
Driving System
Motor power kw 30
Hydraulic pressure mpa 15
Product Range
Suitable Bottle Range ml 3-800
Max. Bottle Height mm ≤200
Max. Dia of bottle mm ≤100
Others
Min. Air pressure mpa 1.0
Discharge rate of compressed air M3/mm ≥0.8
Water flowage M3/h 5
Total rated power with mold heating kw 46.8
Dimension (LxWxH) m 4.5×1.34×2.35
Net weight ton 8.6
